FLYER™ M880
$1,799.00
$1,499.00
(No reviews yet)
Write a Review
FLYER™ M880
Say hello to modern mobility. Delivering high speed, performance, and cargo hauling capabilities, the Flyer™ M880 is the perfect everyday adult electric cargo bike to rekindle the joy & freedom of your first set of wheels. For riders 16 years of age and older.
Powerful Hub Motor: The powerful 500W brushless rear hub motor ensures high performance, maximum efficiency, and a smooth ride.
7-Speed Gear Shifter: Conquer hills fearlessly. The 7-speed Shimano shifter & derailleur allows you to easily shift between gears on your electric power bike to meet your pedaling needs.
Integrated Rear Rack: With compatible accessories ranging from a Large Rear Storage Basket to a Thule® Yepp Maxi Seat , customize the storage on your longtail cargo eBike to address your unique kid & cargo needs.
Puncture Resistant Tires: The 26” front wheel and 20” back wheel on this adult eBike both feature a 3” puncture resistant liner to enhance durability and keep you rolling.
Disc Braking System: The Tektro lever brake system delivers powerful braking on demand. The automatic motor cutoff switch safely stops the electric bicycle when you brake. And don’t forget about the bell, integrated for safe riding.
LCD Display: Control your ride with the digital LCD display, featuring a speedometer, odometer, battery charge level, pedal assist level, and light indicator.
High Intensity LED Headlight: With safety in mind, the high intensity front LED headlight ensures that you can see and be seen. Reflectors and an integrated taillight with brake light also enhance visibility on the go.
Dual-Leg Kickstand: Use the dual leg kickstand on your electric cargo bike for stability while loading & unloading or when not in use. The aluminum step-through frame also assists with easy on & off.
Half Twist Throttle: In addition to 5 levels of pedal assist, use the half twist throttle to move without pedaling at all. It's like having the wind at your back on demand.
| Battery Pack
48V 15Ah (687Wh) UL Tested Lithium-Ion Samsung 50E 21700 Cells |
Charger
54.6V, 2A smart charger Operates on 100-240V AC outlets |
Charge Time
Up to 10 hours |
| Controller
48V 500W |
Display
LCD display that shows speedometer, battery charge level, pedal assist level, odometer, and light indicator |
Lights
Front: LED headlight Rear: Integrated tail light with brake light |
| Motor
500W brushless hub motor |
Pedal Assist
5 level pedal assist with cadence sensor |
Range
30 - 50+ miles |
| Throttle
Half twist throttle |
Speed
Up to 20 MPH |
| Brake Calipers
Tektro Aries MD-M300 |
Crank Set
44T, 170 mm forged alloy, dual-sided aluminum guard |
Tires
Front: 26" x 3.0" puncture resistant liner Rear: 26" x 3.0" puncture resistant liner |
Headset
Semi-integrated, 1-1/8" straight steerer tube |
Saddle
Comfort foam ergonomic saddle, integrated steel seat post, fixed angle |
| Brake Levers
Aluminum alloy levers with motor cutoff switch and integrated bell |
Derailleur
Shimano TY300 7-speed derailleur |
Freewheel
Shimano TZ500 7-speed freewheel |
Kickstand
Steel Dual leg, spring loaded |
Shifter
Shimano SL-TX50-7R shifter |
| Brake Rotors
Tektro 180mm front and rear |
Fenders
Durable impact resistant ABS plastic |
Grips
Durable ergonomic TPE rubber |
Pedals
Integrated reflectors, CrMo axle, standard 9/16" x 20 TPI threading |
Spokes
12-gauge stainless steel, black |
| Chain
KMC Z7 CrMo steel |
Fork
Rigid steel |
Handlebar
Aluminum, 680 mm wide, 48mm rise |
Rims
Steel rims (26" tires) |
Stem
100mm, adjustable handlebar angle up to 60° |
| Frame
6061 Aluminum |
|
|
|
| Seat tube length
18.00" 457mm |
Standover height
19” |
Chainstay
18.50” 470mm |
| Handlebar height (min & max)
Min: 41.0” Max: 43.75” |
Total bike length
73.34" 1863mm |
Bike weight
67 lbs |
| Handlebar reach
16.62" 422.2mm |
Wheelbase
44.21" 1123mm |
Seat height
Min: 27.5" Max: 36.0" |
| Packaging
60" X 11" X 36.5" |
Total package weight
91 lbs |
Age Range
16+ Years Old |
Flyer™ M880 Size Guide
Rider Height (in)
4’10” – 5’8”
5’2” – 6’3”
5’8” – 6’6”
Rider Height (cm)
147 – 173
157 – 191
173 – 198
Recommended Size
Small
Medium
Large
If you are the primary rider and your height falls between two sizes, we recommend selecting the size that puts your height in the middle of the range versus the bottom or top end of the range. For example, if you are 5’ 3”, we would recommend selecting the Small frame. If you are still unsure, we generally recommend sizing down. If the bike is going to be shared among multiple riders, we recommend selecting the size that best captures the height range of all riders.
You can also use our personalized size guide to find the perfect fit for you and any additional riders.
| Front Storage capacity
25 lbs |
| Max Rider capacity
220 lbs |
| Payload capacity
300 lbs |
| Rear rack capacity
80 lbs |
